Wooden pivot with increased resistance to moisture

Roof windows manufactured in pine and vacuum impregnated. Coated with three layers of polyurethane lacquer to form a smooth and uniform surface of the window profiles which is homogeneous without a trace of wood grains.

A popular design of the windows with a hinge located in the middle of the window height, designed for rooms with higher humidity.
Convenient way of using the window as the handle is located at the bottom of the sash. The handle is equipped with a two step micro-opening facilty.
Easy cleaning of the outer pane and operating an awning blind with the use of blocking sash bolt when rotated through 180 degrees.
Available as standard with energy-saving glazing U3.
Increased resistance to burglary - TopSafe system.
The thermoPro technology applied enhances the performance of roof windows by improving energy-efficiency parameters, supporting the air-tightness of the window system and facilitating installation.
A wide range of accessories.
Wide range of flashings designed for window installation in various types of roof coverings.
Possibility to install electrical control.
Installation in roof pitches from 15 to 90 degrees.

With increased resistance to moisture

thermoPro technology as standard

Topsafe® system of burglary protection as standard

Distribution Contact Article Case study: Vienna

Get inspired

FTU-V
- automatic air V40P
- U3 - Energy saving double glazed unit:
  Uw=1,3W/m²K with standard flashing,
  Uw=1,2W/m²K with EHV-AT Thermo flashing,
- pine wood, glued in layers and vacuum impregnated
- three coats of polyurethane varnish ideal for creating a durable and smooth finish in white on the surface of the frame
- Designed for rooms with periodically increased humidity (kitchens, bathrooms)
- Installation in roof pitches from 15 to 90 degrees
- 1.3 W/m²K window U-value 1.0 W/m²K glazing U-value 32 dB acoustic insulation Rw 4H-16-4T glazing unit argon inert gas filled panes + external glass toughened V40P air inlet type up to 49m³/h air inlet air flow triple varnishing four seals + multi-point opening Elegant handle
- 0.97 W/m²K window U-value 0.5 W/m²K glazing U-value 33 dB acoustic insulation Rw 4HT-10-4H-10-4HT glazing unit krypton inert gas filled panes + external glass toughened V40P air inlet type up to 49m³/h air inlet air flow triple varnishing four seals + multi-point opening Elegant handle
- 1.3 W/m²K window U-value 1.0 W/m²K glazing U-value 35dB acoustic insulation Rw 4HS-15-33.1T glazing unit argon inert gas filled panes + external glass toughened V40P air inlet type up to 49m³/h air inlet air flow triple varnishing four seals + multi-point opening Elegant handle
